Intro

If you've landed on this page, it means you, like me, have faced the task of installing Mastodon on your Kubernetes cluster. I tried to solve this problem for quite a long time, as I only recently started learning Kubernetes and encountered many ways to do this - some didn't fit my specific case, some were already outdated. So I decided to write this guide for people like me, for whom it's important to get everything running, see that everything works, and then continue with fine-tuning.

Disclaimer: I'm not an expert and obviously this isn't the best or most correct way to install Mastodon on Kubernetes. I'm deliberately not using Helm to have as much control as possible over everything and to learn more about working with Kubernetes.

I use a GitOps approach with ArgoCD, so here I'll stick to the same storytelling method. But you can apply the yaml files without uploading them to git - it doesn't really matter much. The most important thing is that I'm sharing completely working configs that are successfully and reliably running right now on my personal Mastodon instance dol.social. If you follow this guide exactly, everything will work for you too. If there are any difficulties or errors - I'd be happy to hear your comments.

Also, if you have any suggestions - I'd be happy to hear them too. This is important to me.

Well then, let's begin.

My config

  • Kubernetes version 1.33
  • 1 load balancer
  • 3 nodes with 4GB RAM, 2 cores and 20GB SSD each
  • cert-manager for automatic certificate generation
  • nginx ingress (you can use Traefik or another one, it's not essential)
  • kubeseal for secure secret storage

What we will be installing

  • Mastodon 4.4.5
  • PostgreSQL 17.6 (the latest at the time of writing, for future-proofing)
  • Redis 7
  • Mastodon Streaming
  • Mastodon Sidekiq
  • S3-Compatible Object Storage with CDN
  • Cron job for automatic daily cleanup of outdated media files, so storage doesn't grow infinitely
  • Cron job for automatic daily full backup of database and files via rclone with subsequent upload to AWS S3
  • Horizontal autoscaler for sidekiq, so that additional pods are launched during peak loads instead of one giant pod

I decided not to install ElasticSearch as it consumes a lot of RAM, and for my personal instance it doesn't make much sense. If it becomes necessary, let me know and I'll write instructions for that too.

Getting Started

First, make sure you have all the necessary programs and tools installed.

I recommend using kubeseal for secure secret storage. I use macOS, so I can only guarantee the functionality and accuracy of commands for this platform.

But first, we need to install the Kubeseal Controller if it's not already installed:

kubectl apply -f https://github.com/bitnami-labs/sealed-secrets/releases/download/v0.32.2/controller.yaml

After this, you can proceed to install Kubeseal on your local machine.

To install kubeseal on macOS, you can use brew:

brew install kubeseal

For Linux, you can use the following commands:

# Latest version as for 28.09.2025
export KUBESEAL_VERSION="0.32.2"

curl -OL "https://github.com/bitnami-labs/sealed-secrets/releases/download/v${KUBESEAL_VERSION}/kubeseal-${KUBESEAL_VERSION}-linux-amd64.tar.gz"

tar -xvzf kubeseal-${KUBESEAL_VERSION}-linux-amd64.tar.gz kubeseal

sudo install -m 755 kubeseal /usr/local/bin/kubeseal

rm kubeseal-${KUBESEAL_VERSION}-linux-amd64.tar.gz

If you are using Go, it can be done with one command directly from the source.

go install github.com/bitnami-labs/sealed-secrets/cmd/kubeseal@main

Now check the installation and ensure everything is working correctly:

kubeseal --version

It should output

 kubeseal version: v0.32.2

If everything is okay, we can move on to the next step.

Creating a Namespace

I chose the namespace 'mastodon' but you can choose another.

apiVersion: v1
kind: Namespace
metadata:
  name: mastodon

namespace.yaml

kubectl apply -f namespace.yaml

Apply it

Ingress Configuration

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: mastodon-ingress
  namespace: mastodon
  annotations:
    cert-manager.io/cluster-issuer: "letsencrypt-prod"
    nginx.ingress.kubernetes.io/ssl-redirect: "true"
spec:
  ingressClassName: nginx
  tls:
    - hosts:
        - your-domain.com
      secretName: your-domain.com-tls
  rules:
    - host: your-domain.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: mastodon-web
                port:
                  number: 80
          - path: /api/v1/streaming
            pathType: Prefix
            backend:
              service:
                name: mastodon-streaming
                port:
                  number: 4000

ingress.yaml

kubectl apply -f ingress.yaml

Apply it

Creating PVCs

Let’s create PVCs for Redis and Postgres. You may also use StatefulSet, but in my case, I chose PVC as I don't plan on scaling Postgres for now. I may update or supplement this guide later. For Ghost and Umami Analytics, I used StatefulSet, and instructions will come later.

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: postgres-pvc
  namespace: mastodon
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 10Gi

pvc-postgres.yaml

kubectl apply -f pvc-postgres.yaml

Apply it

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: redis-pvc
  namespace: mastodon
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 5Gi

pvc-redis.yaml

kubectl apply -f pvc-redis.yaml

Apply it

Creating Services

Postgres Service

apiVersion: v1
kind: Service
metadata:
  name: postgres
  namespace: mastodon
spec:
  ports:
    - port: 5432
  selector:
    app: postgres
  clusterIP: None

svc-postgres.yaml

kubectl apply -f svc-postgres.yaml

Apply it

Mastodon Web Service

apiVersion: v1
kind: Service
metadata:
  name: mastodon-web
  namespace: mastodon
spec:
  selector:
    app: mastodon-web
  ports:
    - port: 80
      targetPort: 3000

svc-mastodon-web.yaml

kubectl apply -f svc-mastodon-web.yaml

Apply it

Redis Service

apiVersion: v1
kind: Service
metadata:
  name: redis
  namespace: mastodon
spec:
  ports:
    - port: 6379
  selector:
    app: redis
  clusterIP: None

svc-redis.yaml

kubectl apply -f svc-redis.yaml

Apply it

Mastodon Streaming Service

apiVersion: v1
kind: Service
metadata:
  name: mastodon-streaming
  namespace: mastodon
spec:
  selector:
    app: mastodon-streaming
  ports:
    - port: 4000
      targetPort: 4000

svc-mastodon-streaming.yaml

kubectl apply -f svc-mastodon-streaming.yaml

Apply it

Creating Secrets

To create the necessary secrets for Mastodon, we need to have generated constants that must never be changed once set in our environment.

Here’s the list:

ACTIVE_RECORD_ENCRYPTION_DETERMINISTIC_KEY=<32 bytes min>
ACTIVE_RECORD_ENCRYPTION_KEY_DERIVATION_SALT=<20 bytes min>
ACTIVE_RECORD_ENCRYPTION_PRIMARY_KEY=<12 bytes min>
SECRET_KEY_BASE=<64 bytes>
OTP_SECRET=<64 bytes>
VAPID_PRIVATE_KEY=<32 bytes>
VAPID_PUBLIC_KEY=<65 bytes>

They're required to run your Mastodon instance

The easiest way to generate Active Record Encryption Keys is using Docker with a single command:

docker run --rm -it --entrypoint /bin/bash lscr.io/linuxserver/mastodon:latest generate-active-record

After executing the command, you will receive a similar message:

# Do NOT change these variables once they are set
ACTIVE_RECORD_ENCRYPTION_DETERMINISTIC_KEY=YOUR_DETERMINISTIC_KEY_HERE
ACTIVE_RECORD_ENCRYPTION_KEY_DERIVATION_SALT=YOUR_DERIVATION_SALT_KEY
ACTIVE_RECORD_ENCRYPTION_PRIMARY_KEY=YOUR_PRIMARY_KEY

Save them and proceed to the next step.

For SECRET_KEY_BASE and OTP_SECRET, run the command twice.

docker run --rm -it tootsuite/mastodon:latest sh -c "bundle exec rake secret"

For the VAPID_PRIVATE_KEY and VAPID_PUBLIC_KEY, use the following command:

docker run --rm -it tootsuite/mastodon:latest sh -c "bundle exec rake mastodon:webpush:generate_vapid_key"

Important Notes

  • SECRET_KEY_BASE is used for encrypting browser sessions—changing it will break all active sessions.
  • OTP_SECRET is used for two-factor authentication—changing it will break 2FA for all users.
  • VAPID keys are used for push notifications—changing them will break notifications.
  • All these keys must be generated only once and never changed.

Now we need to add all these keys to the mastodon-env secret (or whatever you choose to name it).

Create a file mastodon-env.yaml with the following content (you can modify it according to your requirements).

apiVersion: v1
kind: Secret
metadata:
  name: mastodon-env
  namespace: mastodon
type: Opaque
stringData:
  SECRET_KEY_BASE: "SECRET_YOU_GENERATED_ABOVE"
  OTP_SECRET: "SECRET_YOU_GENERATED_ABOVE"
  VAPID_PRIVATE_KEY: "SECRET_YOU_GENERATED_ABOVE"
  VAPID_PUBLIC_KEY: "SECRET_YOU_GENERATED_ABOVE"
  ACTIVE_RECORD_ENCRYPTION_DETERMINISTIC_KEY: "SECRET_YOU_GENERATED_ABOVE"
  ACTIVE_RECORD_ENCRYPTION_KEY_DERIVATION_SALT: "SECRET_YOU_GENERATED_ABOVE"
  ACTIVE_RECORD_ENCRYPTION_PRIMARY_KEY: "SECRET_YOU_GENERATED_ABOVE"
  SINGLE_USER_MODE: "true"
  LOCAL_DOMAIN: "your-domain.com"
  WEB_DOMAIN: "your-domain.com"
  DB_HOST: "postgres" // or postgres.mastodon.svc.cluster.local
  DB_PASS: "your_postgres_password" // define your secure password here
  REDIS_HOST: "redis" // or redis.mastodon.svc.cluster.local
  REDIS_PORT: "6379"
  SMTP_SERVER: "smtp.eu.mailgun.org" // or your own SMTP server
  SMTP_PORT: "587" // if you use secure SMTP
  SMTP_LOGIN: "mail@your-domain.com"
  SMTP_PASSWORD: "your_smtp_password"
  SMTP_FROM_ADDRESS: "mail@blog.dol.ch"
  CACHE_REDIS_URL: "redis://redis:6379/1" // or redis://redis.mastodon.svc.cluster.local:6379/1
  RAILS_CACHE_STORE: "redis_cache_store"
  S3_ENABLED: "true" // we'll configure S3 later
  S3_BUCKET: "bucket_name" // change it to your desired bucket name
  S3_REGION: "us-east-1" // your S3 region
  AWS_ACCESS_KEY_ID: "" // your S3 access_key_id here
  AWS_SECRET_ACCESS_KEY: "" // your S3 secret_access_key here
  S3_ENDPOINT: "" // your S3 endpoint here
  S3_FORCE_PATH_STYLE: "true" // it is recommended if you use S3 compatible provider
  S3_ALIAS_HOST: "cdn.your-domain.com" // if you use CDN, put the name here

mastodon-env.yaml

Creating Sealed Secrets

To prevent our sensitive data from being stored in the open, we will use Kubeseal to encrypt them with our controller and store them in Git. Never store API keys, passwords, and other sensitive data in a Git repo!

Execute the following command

kubeseal --controller-namespace kube-system --controller-name sealed-secrets-controller --format yaml < mastodon-env.yaml > sealed-mastodon-env.yaml

Then, it's best to delete mastodon-env.yaml and create our sealed secret in the cluster:

kubectl apply -f sealed-mastodon-env.yaml

Now we have everything to begin creating our deployments.

Creating Deployments

Let’s start with Postgres. I decided to choose version 17.6 at the time of writing, as it is fully compatible with Mastodon 4.4.5 and won’t need updating even in the event of a major Mastodon update. You may change the version as you wish.

Postgresql

apiVersion: apps/v1
kind: Deployment
metadata:
  name: postgres
  namespace: mastodon
spec:
  replicas: 1
  selector:
    matchLabels:
      app: postgres
  template:
    metadata:
      labels:
        app: postgres
    spec:
      containers:
        - name: postgres
          image: postgres:17.6
          env:
            - name: POSTGRES_DB
              value: mastodon_production
            - name: POSTGRES_USER
              value: mastodon
            - name: POSTGRES_PASSWORD
              valueFrom:
                secretKeyRef:
                  name: mastodon-env
                  key: DB_PASS
            - name: PGDATA
              value: /var/lib/postgresql/data/pgdata
          ports:
            - containerPort: 5432
          volumeMounts:
            - name: postgres-data
              mountPath: /var/lib/postgresql/data
            - name: dshm
              mountPath: /dev/shm
      volumes:
        - name: postgres-data
          persistentVolumeClaim:
            claimName: postgres-pvc
        - name: dshm
          emptyDir:
            medium: Memory
            sizeLimit: 256Mi

postgres-deployment.yaml

kubectl apply -f deployment-postgres.yaml

Apply it

Redis

apiVersion: apps/v1
kind: Deployment
metadata:
  name: redis
  namespace: mastodon
spec:
  replicas: 1
  selector:
    matchLabels:
      app: redis
  template:
    metadata:
      labels:
        app: redis
    spec:
      containers:
        - name: redis
          image: redis:7-alpine
          ports:
            - containerPort: 6379
          volumeMounts:
            - name: redis-data
              mountPath: /data
          command:
            - redis-server
            - "--appendonly"
            - "yes"
      volumes:
        - name: redis-data
          persistentVolumeClaim:
            claimName: redis-pvc

deployment-redis.yaml

kubectl apply -f deployment-redis.yaml

Apply it

Streaming

apiVersion: apps/v1
kind: Deployment
metadata:
  name: mastodon-streaming
  namespace: mastodon
spec:
  replicas: 1
  selector:
    matchLabels:
      app: mastodon-streaming
  template:
    metadata:
      labels:
        app: mastodon-streaming
    spec:
      containers:
        - name: streaming
          image: ghcr.io/mastodon/mastodon-streaming:v4.4.5
          envFrom:
            - secretRef:
                name: mastodon-env
          ports:
            - containerPort: 4000
          command:
            - node
            - ./streaming/index.js

deployment-streaming.yaml

kubectl apply -f deployment-streaming.yaml

Apply it

Mastodon Web (Puma)

apiVersion: apps/v1
kind: Deployment
metadata:
  name: mastodon-web
  namespace: mastodon
spec:
  replicas: 1
  selector:
    matchLabels:
      app: mastodon-web
  template:
    metadata:
      labels:
        app: mastodon-web
    spec:
      securityContext:
        fsGroup: 1000
      initContainers:
        - name: volume-permissions
          image: busybox
          command: [ "sh", "-c", "chmod -R u+rwX /mastodon/public/system" ]
          securityContext:
            runAsUser: 0
          volumeMounts:
            - mountPath: /mastodon/public/system
              name: system-files
      containers:
        - name: web
          image: tootsuite/mastodon:v4.4.5
          volumeMounts:
            - name: system-files
              mountPath: /mastodon/public/system
          envFrom:
            - secretRef:
                name: mastodon-env
          env:
              - name: WEB_CONCURRENCY
                value: "1"
              - name: MAX_THREADS
                value: "3"
              - name: DB_POOL
                value: "5"
              - name: MALLOC_ARENA_MAX
                value: "2"
              - name: RAILS_MAX_THREADS
                value: "3"
          ports:
            - containerPort: 3000
          command:
            - bundle
            - exec
            - puma
            - -C
            - config/puma.rb
          resources:
            requests:
              cpu: "300m"
              memory: "600Mi"
            limits:
              cpu: "600m"
              memory: "1.2Gi"
      volumes:
        - name: system-files
          persistentVolumeClaim:
            claimName: mastodon-system-pvc

deployment-web.yaml

kubectl apply -f deployment-web.yaml

Apply it

Sidekiq

apiVersion: apps/v1
kind: Deployment
metadata:
  name: mastodon-sidekiq
  namespace: mastodon
spec:
  selector:
    matchLabels:
      app: mastodon-sidekiq
  template:
    metadata:
      labels:
        app: mastodon-sidekiq
    spec:
      containers:
        - name: sidekiq
          image: tootsuite/mastodon:v4.4.5
          command:
            - bash
            - -lc
            - >
              bundle exec sidekiq
              -c 5
              -q default,8
              -q push,6
              -q ingress,4
              -q mailers,2
              -q fasp,2
              -q pull,1
              -q scheduler,1
          envFrom:
            - secretRef:
                name: mastodon-env
          env:
            - name: DB_POOL
              value: "5"
            - name: MALLOC_ARENA_MAX
              value: "2"
          resources:
            requests:
              cpu: "500m"
              memory: "300Mi"
            limits:
              cpu: "1000m"
              memory: "600Mi"

deployment-sidekiq.yaml

kubectl apply -f deployment-sidekiq.yaml

Apply it

Sidekiq Autoscaler

I preferred a horizontal autoscale for Sidekiq to evenly distribute resources across nodes rather than creating one giant process using 2 CPUs and 3GB of RAM. It's one of the most demanding services, so I decided on up to 3 replicas to start additional pods during peak loads. You may skip this if everything works well for you and there's no intensive federation.

apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler
metadata:
  name: mastodon-sidekiq-hpa
  namespace: mastodon
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: mastodon-sidekiq
  minReplicas: 1
  maxReplicas: 3
  metrics:
    - type: Resource
      resource:
        name: cpu
        target:
          type: Utilization
          averageUtilization: 90

sidekiq-autoscaler.yaml

kubectl apply -f autoscaler-sidekiq.yaml

Apply it

CronJobs

To tackle the infinite expansion of object storage, I prefer a daily cron job for automatic cleanup of unnecessary media files.

Here’s my simple cron job that runs automatically every day at 3 am to keep the storage under control. You can edit it as needed. I've added --verbose flags to easily track errors and overall progress if needed.

apiVersion: batch/v1
kind: CronJob
metadata:
  name: mastodon-media-cleanup
  namespace: mastodon
  labels:
    app: mastodon
    job-type: cleanup
spec:
  schedule: "0 3 * * *"
  jobTemplate:
    spec:
      template:
        spec:
          containers:
            - name: mastodon
              image: tootsuite/mastodon:v4.4.5
              command: ["/bin/bash"]
              args:
                - "-c"
                - |
                  RAILS_ENV=production bin/tootctl media remove --days=7 --verbose && \
                  RAILS_ENV=production bin/tootctl media remove-orphans && \
                  RAILS_ENV=production bin/tootctl preview_cards remove --days=7 --verbose && \
                  RAILS_ENV=production bin/tootctl cache clear && \
                  RAILS_ENV=production bin/tootctl accounts prune && \
                  RAILS_ENV=production bin/tootctl statuses remove --days=7 --verbose
              envFrom:
                - secretRef:
                    name: mastodon-env
          restartPolicy: OnFailure

mastodon-media-cleanup.yaml

Backup

This is one of the tedious tasks, as you’ll need to create your own package in GitHub (or another registry of your choice, or if you know of an existing better option, let me know).

I needed the ability to run pg_dump for my Postgres version 17, use rclone for copying media files from my profile from one S3-compatible source to AWS S3 via rclone, so creating my own package and Bash script was unavoidable.

For this, we need to install AWS CLI, rclone, and PostgreSQL Client 17.

First, create postgres-backup.sh.

Make sure your database user is mastodon, and the database name is mastodon_production; otherwise, change it in the script.

Also, change your rclone configuration name (RCLONE_CONFIG_NAME) to yours. Also, change the bucket name from YOUR_MASTODON_BUCKET to yours.

For S3, don’t forget to change YOUR_S3_DESTINATION_BUCKET to your S3 bucket name.

If you use only S3/S3, you can edit the script at your discretion and not install rclone, for example. This is my personal example of a working script.

#!/bin/bash
cd /home/root

date1=$(date +%Y%m%d-%H%M)
backup_dir="mastodon-backup"
file_name="mastodon-backup-$date1.tar.gz"

mkdir -p $backup_dir/db
mkdir -p $backup_dir/media/accounts
mkdir -p $backup_dir/media/media_attachments

PGPASSWORD="$PG_PASS" pg_dump -h postgres -p 5432 -U mastodon -d mastodon_production -Fc > $backup_dir/db/mastodon-db.dump
if [ $? -ne 0 ]; then
  echo "Error: Failed to create PostgreSQL dump"
  exit 1
fi

rclone sync RCLONE_CONFIG_NAME:YOUR_MASTODON_BUCKET/accounts/ $backup_dir/media/accounts/ --config=/home/root/rclone.conf
if [ $? -ne 0 ]; then
  echo "Error: Failed to copy accounts media files with rclone"
  exit 1
fi

rclone sync RCLONE_CONFIG_NAME:YOUR_MASTODON_BUCKET/media_attachments/ $backup_dir/media/media_attachments/ --config=/home/root/rclone.conf
if [ $? -ne 0 ]; then
  echo "Error: Failed to copy media attachments with rclone"
  exit 1
fi

media_size=$(du -sb $backup_dir/media | cut -f1)
if [ "$media_size" -lt 1024 ]; then
  echo "Warning: Media files size is too small ($media_size bytes)"
fi

tar -zcvf $file_name $backup_dir
if [ $? -ne 0 ]; then
  echo "Error: Failed to create archive"
  exit 1
fi

if [ "$(stat -c %s $file_name)" -gt 10 ]; then
  aws s3 cp $file_name s3://YOUR_S3_DESTINATION_BUCKET/
  if [ $? -ne 0 ]; then
    echo "Error: Failed to upload backup to S3"
    exit 1
  fi
  echo "Backup successful: $file_name"
else
  echo "Backup failed: Archive size too small"
  exit 1
fi

rm -rf $backup_dir $file_name

postgres-backup.sh

Here’s my Dockerfile (remove unnecessary parts if your config differs)

FROM ubuntu:24.04
RUN apt-get update && apt-get upgrade -y
RUN apt-get install -y python3 python3-venv curl gnupg2 unzip
RUN python3 -m venv /opt/venv
ENV PATH="/opt/venv/bin:$PATH"
RUN curl -sO https://bootstrap.pypa.io/get-pip.py && python3 get-pip.py
RUN pip install awscli
RUN echo "deb http://apt.postgresql.org/pub/repos/apt/ noble-pgdg main" | tee /etc/apt/sources.list.d/pgdg.list
RUN apt-key adv --keyserver keyserver.ubuntu.com --recv-keys 7FCC7D46ACCC4CF8
RUN apt update && apt -y install postgresql-client-17
# Install rclone
RUN curl -O https://downloads.rclone.org/rclone-current-linux-amd64.zip && \
    unzip rclone-current-linux-amd64.zip && \
    mv rclone-*/rclone /usr/bin/ && \
    rm -rf rclone-*
COPY postgres-backup.sh /home/root/
COPY rclone.conf /home/root/
RUN chmod +x /home/root/postgres-backup.sh
USER root
CMD ["/bin/bash"]

Dockerfile

If you already have your configured rclone.conf, just use it or create a new one by example. I use Infomaniak Public Cloud, which works via Swift, so the config might differ, double-check this.

[infomaniak]
type = swift
env_auth = true
user = YOUR_USER
key = YOUR_PASSWORD
auth = YOUR_AUTH_URL
domain = default
tenant = YOUR_TENANT
tenant_domain = default
region = YOUR_REGION

rclone.conf

Create or use your existing repository for the upcoming package upload.

Now build the image.

docker build --progress=plain -f Dockerfile -t ghcr.io/YOUR_GITHUB_ACCOUNT/YOUR_REPO:latest --platform linux/amd64 .

If you work on MacOS with ARM chips, specifying --platform linux/amd64 is mandatory, otherwise, your image will build for ARM and not run on your x86 server.

If everything is okay, upload your image.

docker push ghcr.io/YOUR_GITHUB_ACCOUNT/YOUR_REPO:latest

If successful, proceed with setup.

Now create ghcr and aws secrets. The easiest way is to create them with the command:

kubectl create secret docker-registry mastodon-ghcr-secret \
  --docker-server=ghcr.io \
  --docker-username=YOUR_USERNAME \
  --docker-password=YOUR_TOKEN \
  --namespace=mastodon \
  --dry-run=client -o yaml > mastodon-ghcr-secret.yaml

And

kubectl create secret generic mastodon-backup-secrets \
  --from-literal=aws_access_key_id=YOUR_ACCESS_KEY \
  --from-literal=aws_secret_access_key=YOUR_SECRET_KEY \
  --from-literal=pg_pass=YOUR_PASSWORD \
  --namespace=mastodon \
  --dry-run=client -o yaml > mastodon-backup-secret.yaml

You will get files in the following format:

apiVersion: v1
kind: Secret
metadata:
  name: mastodon-ghcr-secret
  namespace: mastodon
type: kubernetes.io/dockerconfigjson
data:
  .dockerconfigjson: YOUR_BASE64_AUTH_DATA

mastodon-ghcr-secret.yaml

apiVersion: v1
kind: Secret
metadata:
  name: mastodon-ghcr-secret
  namespace: mastodon
type: kubernetes.io/dockerconfigjson
data:
  aws_access_key_id: YOUR_BASE64_AUTH_DATA
  aws_secret_access_key: YOUR_BASE64_AUTH_DATA
  pg_pass: YOUR_BASE64_AUTH_DATA

mastodon-backup-secret.yaml

Now we need to encrypt these secrets using kubeseal and delete them.

kubeseal --controller-namespace kube-system --controller-name sealed-secrets-controller --format yaml < mastodon-ghcr-secret.yaml > sealed-mastodon-ghcr-secret.yaml
kubeseal --controller-namespace kube-system --controller-name sealed-secrets-controller --format yaml < mastodon-backup-secret.yaml > sealed-mastodon-backup-secret.yaml

Apply them

kubectl apply -f sealed-mastodon-ghcr-secret.yaml
kubectl apply -f sealed-mastodon-backup-secret.yaml

Don’t forget to delete mastodon-ghcr-secret.yaml and mastodon-backup-secret.yaml.

Now everything's ready to create our Backup Cronjob. Every night at 4 am.

apiVersion: batch/v1
kind: CronJob
metadata:
  name: mastodon-full-backup
  namespace: mastodon
spec:
  schedule: "0 4 * * *"
  jobTemplate:
    spec:
      template:
        spec:
          imagePullSecrets:
            - name: mastodon-ghcr-secret
          containers:
            - name: backup-job
              image: ghcr.io/YOUR_GITHUB_ACCOUNT/YOUR_REPO:latest
              env:
                - name: PG_PASS
                  valueFrom:
                    secretKeyRef:
                      name: mastodon-backup-secrets
                      key: pg_pass
                - name: AWS_ACCESS_KEY_ID
                  valueFrom:
                    secretKeyRef:
                      name: mastodon-backup-secrets
                      key: aws_access_key_id
                - name: AWS_SECRET_ACCESS_KEY
                  valueFrom:
                    secretKeyRef:
                      name: mastodon-backup-secrets
                      key: aws_secret_access_key
                - name: AWS_DEFAULT_REGION
                  value: "eu-central-2"
                - name: S3_BUCKET
                  value: "YOUR_BUCKET/mastodon-backups"
              command: ["/bin/bash", "-c", "cd /home/root && ./postgres-backup.sh"]
              imagePullPolicy: Always
          restartPolicy: OnFailure
      backoffLimit: 3

cron-mastodon-full-backup.yaml

Congratulations, now you have (or at least should have) a working Mastodon instance on Kubernetes with automatic daily backups and secure secret storage.

I would appreciate any comments, questions, or suggestions and will update this guide as Kubernetes & Mastodon evolve.
